a) Dome light design, professional reading laser engraving, mechanical dot and inkjet printing and other DPM industrial bar code
b) A new generation of dual camera decoding engine, intelligent three-color lighting
c) Mobydata software service is supported
| Specifications | |
| OS | Android 12 |
| CPU | MT8768A，Octa Core CPU, 12nm |
| MEMORY | 3+32 |
| Extend Slot | MicroSD, support SDHC, up to 128GB; |
| Nano | |
| PC Communication | USB 2.0 OTG : Type-C； |
| Sensers | Gravity sensor, proximity detector, Photosensitive sensor , Hall element, status lamp |
| LED | Charging, Scan and System stauts |
| Charging Time | ≤2.5 h (Room Temperature) |
| Operation Duration | 18 hours |
| Data Collection | |
| Scan Engine | Support VGA Dual Camera scan engine of Mobydata E3350 |
| 2D | Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code |
| Micro QR Code; QR Code; EAN/JAN Composites; GS1 DataBar Composites; | |
| GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; | |
| GS1 DataBar Stacked Omnidirectional; MacroPDF; | |
| MicroPDF417; PDF417; UPC A/E Composites;Digimarc(E3250 supports) | |
| 1D | Auto discriminates all standard 1D codes including GS1，code39，code 128，code93 |
| DataBar™ linear codes. | |
| Post | Australian Post; British Post; China Post; IMB; Japanese |
| Post; KIX Post; Korea Post; Planet Code; Postnet; Royal | |
| Mail Code (RM4SCC) | |
| NFC(Optional) | 13.56MHz NFC |
| Wireless Connectivity | |
| WLAN | 802.11 a/b/g/n/ac, 5G FEM PA |
| WWAN | WWAN ROW GSM: QB UMTS: B1/B2/B5/B8 FDD_LTE:B1/2/3/5/7/8/20/28 TDD_LTE:B34/B38/39/40/41 |
| WWAN NA GSM: QB UMTS: B1/B2/B5/B8 FDD_LTE:B2/B4/B5/B7/B12/B17/B25/B26 | |
| VoLTE | LTE CAT6 |
| CA | Downlink 300Mbps, B1/B3/B39/B40/B41 |
| WPAN | BT 5.1 |
| GPS | GPS/Glonass/Beidou,Assisted GPS |
| Physical Specifications | |
| LCD | 4” , IPS, 800*480, 450nits |
| Touch | Capacitive screen, High strength glass |
| Camera | Auto focus 13Mega, dual flash LED |
| Keypad | Left/Right Scan Key, Vol+/Vol- Key, Power Key，K1/K2 Function Key |
| Reciver | Support |
| Speaker | Double speaker, Greater than 100db |
| Mic | Double Mic with Noise Reduction |
| Charging IO | USB type-C |
| Battery | Removable 5100mAh, Built-in small battery80mA, 8C |
| Dimension | 216mm×82mm×76mm |
| Weight | 378g(With battery) |
| Environmental Specifications | |
| Operation Temperature | -25°C to 55°C |
| Storage Temperature | -30°C to 70°C |
| Humidity | 5%-95% non-condensing |
| Drop | 1.5m on concrete, 1 times on each side |
| Tumble | 1000 hits of 0.5m tumble |
| IP | IP67 |
| ESD | ± 8 kV contact discharge, ± 15 kV air discharge, |
| Keypad lifecycle | 100k |
| Gift Box | |
| Device, QSG, Adapter, USB cable，Battery |
| Optional Accessory | |
| Single host charger, Battery |
| Warranty | |
| Labor warranty for parts for 12 months |
