a) Large-aperture lens design
b) Professional mobile barcode reader
c) Self-sensing image capture
d) Supports motion reading with high scanning sensitivity
e) Scanning angle adjustable by 55° forward and backward
f) Sleek design, available in multiple color options
| Physical Characteristics | |
| Dimensions: | 83mm x 80mm x 147mm |
| Weight: | 133g |
| Voltage: | 3.3-5 VDC |
| Working Current: | 200mA |
| Standby Current: | 90mA |
| Peak Current: | 300mA |
| Performance Characteristics | |
| Image (Pixels): | 640 pixels (H)x 480 pixels (V) |
| Light Source: | Illumination:6500K LED |
| Field of View: | 72° (H) x 64° (V) |
| Roll / Pitch / Yaw: | 360°, ±65°, ±60° |
| Print Contrast: | 20% minimum reflective difference |
| Interfaces Supported: | USB, RS232 |
| Motion Tolerance s: | >2m/s |
| Symbology Decode Capability | |
| 1-D: | UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar Interleaved 2 of 5, Mis Plessey, GSI DataBar, China Postal, Korean Postal , etc |
| 2-D: | PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec Hanxin, etc. |
| Minimum Resolution: | ≥3.9 mil |
| User Environment | |
| Operating Temperature: | -30°C to 70°C |
| Storage Temperature: | -40°C to 70°C |
| Humidity: | 0% to 95% relative humidity,non-condensing |
| Shock Specifications: | Designed to withstand 1.5m(5’) drops |
| Ambient Light Immunity: | 0-100,000 Lux. |
| Decode Ranges | |
| 6.88 mil (PDF417) | 0mm-50mm |
| 10 mil (Data Matrix) | 0mm-50mm |
| 13 mil (UPCA) | 5mm-110mm |
| 20 mil (QR) | 0mm-100mm |
| Performance may be impacted by bar code quality and environmental conditions | |
